DSPCM-4X4SG 4ch DSP w/Bluetooth 600w Amp & 4 Component Speaker H-D® Street Glide® Complete System
DSPCM-4X4SG 4ch DSP w/Bluetooth 600w Amp & 4 Component Speaker H-D® Street Glide® Complete System
Kit Includes:
DSP600.4D – DSP 4 channel by 150W @ 2 ohms Amplifier
CHDSSGTK – 2014+ Street Glide® Grills with RR075T Tweeters – Matched Pair
CM65.4 – 6.5″ Mid-Bass Loudspeaker – 4 ohm – Pair
HDPG8K 8 AWG Power/Ground Wire Kit
-
DSPCM-4X4RG 4ch 600w DSP w/Bluetooth Amp & 4 Component Speaker H-D® Road Glide® Complete System
DSPCM-4X4RG 4ch 600w DSP w/Bluetooth Amp & 4 Component Speaker H-D® Road Glide® Complete System
Kit Includes:
DSP600.4D – DSP 4 channel by 150W @ 2 ohms Amplifier
CHDRGGTK – 2014+ Road Glide® Kidney Grills with RR075T Tweeters – Matched Pair
CM65.4 – 6.5″ Mid-Bass Loudspeaker – 4 ohm – Pair
HDPG8K – 8 AWG Power/Ground Kit
HDFIMY – H-D® Input Molex® – FRONT/Y Bridging Harness
HDFRBOM-1.5 – H-D® Output Molex® – FRONT Bridging Harness – 1.5 feet
-
CX150.4D 4 Channel 600W Full Range Class D Amplifier
4 CHANNEL POWER AMPLIFIER
- 4 X 70 WRMS into 4 ohms @ 12.5 Vdc
- 4 X 92 WRMS into 4 ohms @ 14.4 Vdc
- 4 X 115 WRMS into 2 ohms @ 12.5 Vdc
- 4 X 152 WRMS into 2 ohms @ 14.4 Vdc
BRIDGED MONO – 2 CHANNEL
- 2 X 218 WRMS into 4 ohms @ 12.5 Vdc
- 2 X 302 WRMS into 4 ohms @ 14.4 Vdc
- Frequency response – 20-20,000 +/- 3dB THD < 0.5%
- Operating Voltage: 8V – 16V
- Current Draw (Music): 40 A
- Current Draw (Max): 80 A
- Recommended Fuse (Music): 40 A
- Total Efficiency: 79%
- Damping Factor: 200
- SNR: 91dB
- Crossover LPF/FULL/HPF : 40 TO 400Hz
- Slope:12dB per octave
- Gain : 0.2V – 12 Vac
- Turn-On Configuration: REM/VOX/DC
- THD + N (10% Rated Power): 0.1%
- Product Dimensions (Inches / Millimeters): 7.0 x 4.0 x 1.375 in / 177.8 x 101.6 x 34.9 mm
-
CXCX-4X4 4ch 600w CX Amp & 4 Coax Speaker H-D® Complete System
Kit Includes:
CX150.4D – 4 channel by 150W @ 2 ohms Amplifier
CX65.2- 6.5″ Coaxial Loudspeaker – 2 ohm – Pair
CX69.2- 6×9″ Coaxial Loudspeaker – 2 ohm – Pair
CHDRGG – Front Road Glide® Cicada Logo Grills – Pair
CHDSGG – Front Street Glide® Cicada Logo Grills – Pair
CHDLID – H-D® 2014+ Cut -In Lid Kit – Matched Pair
-
CXCH-4X4 4 ch 600w CX Amp & 4 Horn Speaker H-D® Complete System
Kit Includes:
CX150.4D – 4 channel by 150W @ 2 ohms Amplifier
CH65.2- 6.5″ Coax Horn Loudspeaker – 2 ohm – Pair
CH69.2- 6×9″ Coax Horn Loudspeaker – 2 ohm – Pair
CHDRGG – Front Road Glide® Cicada Logo Grills – Pair
CHDSGG – Front Street Glide® Cicada Logo Grills – Pair
CHDLID – 2014+ H-D(r) LID CUT IN KIT
-
DSPCX-4X4 4ch 600w DSP w/Bluetooth Amp & 4 Coax Speaker
Kit Includes:
(1) DSP600.4D DSP CONTROLLED 4 CHANNEL POWER AMPLIFIER
(1 PR) CX65.2 – 6.5“ COAX HORN SPEAKERS 2OHM
(1 PR) CX69.2 – 6X9″ COAX HORN SPEAKERS 2OHM
(1PR) CHDRGG – 2014 + H-D® Road Glide® Kidney Grill Set
(1PR) CHDSGG – 2014 + H-D® Street Glide® Grill Set
(1 PR) CHDLID 2014+ H-D(r) 6X9″ CICADA LID CUT IN KIT
-
DSPCH-4X4 4ch 600w DSP w/Bluetooth Amp & 4 Coax Horn Speaker
Kit Includes:
(1) DSP600.4D DSP CONTROLLED 4 CHANNEL POWER AMPLIFIER
(1 PR) CH65.2 – 6.5“ COAX HORN SPEAKERS 2OHM
(1 PR) CH69.2 – 6X9″ COAX HORN SPEAKERS 2OHM
(1PR) CHDRGG – 2014 + H-D® Road Glide® Kidney Grill Set
(1PR) CHDSGG – 2014 + H-D® Street Glide® Grill Set
(1 PR) CHDLID 2014+ H-D(r) 6X9″ CICADA LID CUT IN KIT
-
DSPCH-4X2 4ch 600w DSP w/Bluetooth Amp & 2 Coax Horn Speaker
Kit Includes:
(1) DSP600.4D DSP CONTROLLED 4 CHANNEL POWER AMPLIFIER
(1 PR) CH65.4 – 6.5“ COAX HORN SPEAKERS
(1PR) CHDRGG – 2014 + H-D® Road Glide® Kidney Grill Set
(1PR) CHDSGG – 2014 + H-D® Street Glide® Grill Set
-
CXCH-2X2 2ch CX Amp & 2 Coax Horn Speaker H-D® Complete System
Kit Includes:
CX250.2 – 2 channel by 250W @ 2 ohms Amplifier
CH65.2 – 6.5″ Coaxial Horn Loudspeaker – 2 ohm – Pair
CHDRGG – Front Road Glide® Cicada Logo Grills – Pair
CHDSGG – Front Street Glide® Cicada Logo Grills – Pair
HDPG8K – Complete 8 AWG, Power/Ground, Fused Power Wire Kit
HDFIM – H-D® Input Molex® Front
HDFRBOM1.5 – H-D® Output Molex® Front
-
CXCX-4X2 4ch CX Amp & 2 Coax Speaker H-D® Complete System
Kit Includes:
CX150.4D – 4 channel by 150W @ 2 ohms Amplifier
CX65.2- 6.5″ Coaxial Loudspeaker – 2 ohm – Pair
CHDRGG – Front Road Glide® Cicada Logo Grills – Pair
CHDSGG – Front Street Glide® Cicada Logo Grills – Pair
HDPG8K – Complete 8 AWG, Power/Ground, Fused Power Wire Kit
HDFIM – H-D® Input Molex® Front
HDFOM – H-D® Output Molex® Front
-
DSPCM-4X8SG 4ch DSP w/Bluetooth 600w Amp & 8 Component Speaker H-D® Street Glide® Complete System
DSPCM-4X8SG 4ch DSP w/Bluetooth 600w Amp & 8 Component Speaker H-D® Street Glide® Complete System
Kit Includes:
DSP600.4D – DSP 4 channel by 150W @ 2 ohms Amplifier
CHDSSGTK – 2014+ Street Glide® Grills with RR075T Tweeters – Matched Pair
CM65.2 – 6.5″ Mid-Bass Loudspeaker – 2 ohm – Pair
RR075T – 0.75″ Titanium Shallow Horn Tweeters – Pair
CHD69TB – H-D® 2014+ 6 X 9″ Tweeter Bridge for RR075T Tweeters – Matched Pair
CM69.2 – 6 X 9″ Mid-Bass Loudspeaker – 2 ohm – Pair
CHDLID – H-D® 2014+ Cut in Lid Kit with JIGS – Matched Pair
HDPRO4K – 4 CH DSP600.4D Wiring Kit with HDPG8K 8 AWG Wiring Kit
-
DSPCM-4X8RG 4ch DSP w/Bluetooth 600w Amp & 8 Component Speaker H-D® Road Glide® Complete System
DSPCM-4X8RG 4ch DSP w/Bluetooth 600w Amp & 8 Component Speaker H-D® Road Glide® Complete System
Kit Includes:
- DSP 4 channel by 150W @ 2 ohms Amplifier – DSP600.4D
- 2014+ Road Glide® Kidney Grills with RR075T Tweeters – Matched Pair – CHDRGGTK
- 6.5″ Mid-Bass Loudspeaker – 2 ohm – Pair – CM65.2
- 0.75″ Titanium Shallow Horn Tweeters – Pair – RR075T
- H-D® 2014+ 6 X 9″ Tweeter Bridge for RR075T Tweeters – Matched Pair – CHD69TB
- 6 X 9″ Mid-Bass Loudspeaker – 2 ohm – Pair – CM69.2
- H-D® 2014+ Cut in Lid Kit with JIGS – Matched Pair – CHDLID
- 4 CH DSP600.4D Wiring Kit with HDPG8K 8 AWG Wiring Kit – HDPRO4K
-
CXCX-2X2 2ch CX Amp & 2 Coax Speaker H-D® Complete System
Kit Includes:
CX250.2 – 2 channel by 250W @ 2 ohms Amplifier
CX65.4 – 6.5″ Coaxial Loudspeaker – 4 ohm – Pair
CHDRGG – Front Road Glide® Cicada Logo Grills – Pair
CHDSGG – Front Street Glide® Cicada Logo Grills – Pair
HDPG8K – Complete 8 AWG, Power/Ground, Fused Power Wire Kit
HDFIM – H-D® Input Molex® Front
HDFOM – H-D® Output Molex® Front
